PXW-Z300

Sony PXW-Z300 3-CMOS XDCAM Camcorder

SG$ 10,980.00
View More

For B2B , B2C , please whatsApp at +6596238981 for stock availibilty  ( Also get the FULL Catalog / brochure thru WhatsApp )

A recently introduced flagship handheld XDCAM broadcast camcorder utilizing three 1/2-type 4K Exmor R CMOS image sensors paired with modern AI subject recognition

The latest tech, for the way you work

The PXW-Z300 showcases advanced Sony digital imaging technologies, including three 1/2-type 4K Exmor R® CMOS image sensors with the power-packed BIONZ XR™ image processing engine, and the AI Processing Unit that enhances high-performance shooting at 4K60p with Subject Recognition AF.

Key Features

  • 1/2"-Type Exmor R 3-CMOS Sensor
  • Supports up to UHD 4K60 Recording
  • 17x Optical Zoom, Constant f/1.9 Maximum
  • Dedicated AI Focusing Processor
  • Digital Content Authentication
  • Electronic Variable ND Filter
  • XAVC Intra/Long, MPEG HD422, HEVC Proxy
  • S-Cinetone, ITU709, 709tone, HLG, 3D LUT
  • Multicamera Control App, 4-Ch Audio
  • RTMP, RTMPS, SRT Stream, Chunk Transfer

    Agile News and Production WorkflowsFeatures such as digital signature embedding for authenticity confirmation, efficient file transfer and streaming, and cloud connectivity enable fast, agile news and production workflows.

    • 4K Exmor R CMOS Sensors and BIONZ XR Processor
    The PXW-Z300's BIONZ XR image processor works with the three 4K Exmor R CMOS sensors in real time to capture finely detailed, lifelike images with excellent color reproduction, deep depth of field, and very low noise.


    Sony PXW-Z300 Specs

    Key Specs
    Image Sensor
    1/2"-Type
    Effective Sensor Resolution
    8.29 Megapixel
    Image Stabilization
    Optical in Integrated Lens
    ISO/Gain Sensitivity
    Gain: -3 to 18 dB (-3 to 42 dB Extended)
    Max Recording Modes
    MP4 Proxy/XAVC-I/XAVC-L/MXF
    Up to UHD 4K at 25/29.97/50/59.94/23.98 fps
    Max Video Output
    via SDI/BNC / HDMI
    Up to UHD 4K
    Media/Memory Card Slot
    Dual Slot: CFexpress Type A / SDXC
    Video I/O
    HDMI / BNC
    Mobile App Compatible
    Yes: Android & iOS
    Battery
    Sony BP-U Series
    Imaging
    Image Sensor
    7.6 x 4 mm (1/2"-Type) 3-Chip CMOS
    Effective Sensor Resolution
    Effective: 8.29 Megapixel
    Actual: 12.2 Megapixel
    Image Stabilization
    Optical in Integrated Lens
    Built-In ND Filter
    2 to 7 Stop Electronic ND Filter
    Capture Type
    Video Only
    Exposure Control
    Shutter Type
    Electronic Rolling Shutter
    Shutter Speed
    1/8000 to 64 Seconds
    ISO/Gain Sensitivity
    Gain: -3 to 18 dB (-3 to 42 dB Extended)
    Signal-to-Noise Ratio
    Not Specified by Manufacturer
    Minimum Illumination
    0.0013 Lux at f/1.9 Aperture
    White Balance
    Range: 2000 to 15,000K
    Presets: ATW
    Lens
    Focal Length
    5.6 to 95.2mm (35mm Equivalent: 30.3 to 515mm)
    Zoom
    17x Optical
    Maximum Aperture
    f/1.9
    Minimum Aperture
    f/16
    Minimum Focus Distance
    From Front of Lens: 2" / 5 cm
    Control Rings
    Focus
    Zoom
    Iris
    Focus
    Focus Mode
    Automatic, Manual Focus
    Video Capture
    Internal Recording
    MP4 Proxy/XAVC-I/XAVC-L/MXF
    3840 x 2160 at 25/29.97/50/59.94/23.98 fps
    1920 x 1080p at 23.98/50/25/29.97/59.94 fps
    1920 x 1080i at 50/60.00 fps
    Video Output
    via SDI/BNC / HDMI
    3840 x 2160
    1920 x 1080p
    1920 x 1080i
    Broadcast Output
    NTSC
    PAL
    Fast-/Slow-Motion Support
    Yes
    Interval Recording Modes
    Time-Lapse Video
    Gamma Curve
    HDR-HLG, Rec709, Rec2020, S Cinetone, Sony S-Log 3
    Built-In Microphone
    Stereo
    Audio Recording
    MP4, MXF, XAVC: 4-Channel
    IP Streaming
    RTMP, RTMPS, SRT
    3840 x 2160 at 25p, 29.97p
    1920 x 1080 at 25p, 29.97p, 50p, 59.94p
    1280 x 720 at 25p, 29.97p
    Interface
    Media/Memory Card Slot
    Dual Slot: CFexpress Type A / SDXC
    Internal Storage
    No
    Video I/O
    1x BNC (12G-SDI) Output
    1x HDMI 2.0 Output
    Audio I/O
    2x XLR 3-Pin Microphone Input
    1x 1/8" / 3.5 mm TRS Stereo Headphone Output
    Power I/O
    1x USB-C (20VDC at 5 A) Input
    Other I/O
    1x BNC (Timecode) Input/Output
    1x BNC (Genlock, Reference)
    1x RJ45 (Gigabit Ethernet)
    1x 2.5 mm Sub-Mini (Remote)
    1x 1/8" / 3.5 mm Control
    Wireless
    Wi-Fi 5 (802.11ac)
    Wi-Fi
    Mobile App Compatible
    Yes: Android & iOS
    App Name: Monitor & Control
    Global Positioning (GPS, GLONASS, etc.)
    GPS
    Monitor
    Display Type
    Articulating 3.5" Touchscreen LCD
    Resolution
    2,764,800 Dot
    Viewfinder
    Type
    Support via Video Out Only
    Power
    Battery
    Sony BP-U Series
    Power Consumption
    ≥48 W
    Environmental
    Operating Conditions
    32 to 104°F / 0 to 40°C
    Storage Conditions
    -4 to 140°F / -20 to 60°C
    General
    Shoe Mount
    1x Cold Shoe
    1x Hot Shoe
    Tripod Mount
    1x 1/4"-20 Female
    1x 3/8"-16 Female
    Accessory Mounting Thread
    2x 1/4"-20
    Built-In Video Light
    No
    Dimensions (W x H x D)
    7.2 x 7.9 x 13.1" / 182.5 x 201.9 x 333.9 mm
    Weight
    5.7 lb / 2.6 kg (Body Only)
    6.59 lb / 2.99 kg (With Battery)
    Packaging Info
    Package Weight
    9.47 lb
    Box Dimensions (LxWxH)
    18.8 x 10.9 x 10.7"
